Allgemeine Information
Alp TMX204 LED-kit T8 58W 850 90°
Alp TMX204 LED-kit T8 58W 850 90°
YESSS-Bestellnummer
3049-9212
Produktcode
3006052111
EAN-Code
08720094416694
Produktgruppe
Batten luminaire
Marke
ALP
Serie
Alp TMX204 LED-kit T8 58W
Typ
850 90°
Produktbeschreibung
Nachrüstlösung passend für Philips Montageleiste ohne Linienbeleuchtung, TMX204LS-R58, 1520mm, 850, 90Grad. Mit Adapter für die Montage an einer vorhandenen Wandplatte.
Produktspezifikationen
Lamp type
LED not exchangeable
With light source
Ja
Suitable for number of light sources
1
Lamp holder
None
Material
Aluminium
Housing colour
White
Voltage type
AC
Nominal voltage
220 - 240 V
Type of control gear
LED operating device current-controlled
With control gear
Ja
Dimming 0-10 V
Nein
Dimming 1-10 V
Nein
Dimming DALI
Nein
Dimming DMX
Nein
Dimming DSI
Nein
Dimming potentiometer (integrated)
Nein
Dimming LineSwitch
Nein
Dimming manufacturer's proprietary system
Nein
Dimming mains voltage modulation
Nein
Dimming phase cut-off (trailing edge)
Nein
Dimming phase cut-on (leading edge)
Nein
Dimming programmable
Nein
Dimming RF
Nein
Dimming Sine Wave Reduction
Nein
Dimming Touch and Dim
Nein
Dimming Zigbee
Nein
Dimming with push-button
Nein
Light distributor
Focal lens
Suitable for emergency lighting
Nein
Rated lifetime L70/B50 at 25 °C
100000 h
Degree of protection (IP)
IP40
Degree of protection (NEMA)
1
Protection class according to IEC 61140
I
Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24
Nein
Covering of the luminaire with thermally insulating material possible
Nein
Filament test according to IEC 60695-2-11
650 °C - 30 s
With switch
Nein
With movement sensor
Nein
Suitable for lamp power
32 - 60 W
Max. system power
60 W
Colour of light
White
Colour temperature
4800 - 5200 K
Colour rendering index CRI
80-89
Power factor
0.97
Width
65 mm
Height/depth
85 mm
Length
1520 mm
Type of wiring
Ending
Number of poles
3
Conductor cross section
0.5 mm²
Connection type
Blade terminal
Electrical connection with connector system
Nein
Exchangeable control gear
Nein
Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq)
90 %
Failure rate at median useful life of 50,000 h at 25 °C ambient (tq)
10 %
Constant light output (CLO)
Nein
Colour of light adjustable
No
Luminous flux adjustable
Positions
Beam angle adjustable
No
Compatible with Apple HomeKit
Nein
Compatible with Google Assistant
Nein
Compatible with Amazon Alexa
Nein
IFTTT support available
Nein
Nominal current
250 - 275 mA
Energy efficiency class of the light source according to EU regulation 2019/2015
C
Operation by Bluetooth
Nein
Compatible with Casambi
Nein
With lamp protection basket
Nein
Luminaire efficacy
180 lm/W
Impact strength
IK06
Dimmable
Nein
Dimming DALI-2
Nein
