Allgemeine Information
CPE - EBDHS High bay detector inbouw DALI/DSI
CPE - EBDHS High bay detector inbouw DALI/DSI
YESSS-Bestellnummer
3036-5948
Produktcode
CP100012
EAN-Code
05012774621485
Produktgruppe
Movement sensor/presence detector complete
Marke
CP ELECTRONICS
Serie
CP Electronics
Typ
CP ELECTRONICS CP100012
Produktbeschreibung
Produktspezifikationen
Model
Presence detector
Constant light control
Ja
HVAC-control
Nein
Forced switch on
Ja
Forced switch off
Ja
Animal zone
Nein
Creep-under protection
Nein
Networkable
Nein
Optimum mounting height
15 m
Staircase light controller
Ja
Bridging switch
Nein
Max. reach sideways
20 m
Max. presence range
1385 m²
Max. reach frontally
20 m
Diameter reach on floor
40 m
Suitable for wireless transmission
Nein
Remote operation
Ja
With remote control
Ja
Response value sensitivity adjustable
Ja
Response value luminosity adjustable
Ja
With signal unit
Nein
Teach-function for response value luminosity
Nein
Suitable for ceiling mounting
Ja
Dim function with dimmer basic element
Ja
Mounting method
Flush-mounted
Connection type
Screwed terminal
Material
Plastic
Material quality
Thermoplastic
Halogen free
Ja
Surface protection
Untreated
Surface finishing
matt
Anti-bacterial treatment
Nein
Colour
White
RAL-number (similar)
9002
Transparent
Nein
Degree of protection (IP)
IP65
Impact strength
IK05
Voltage type
AC
Frequency
50 - 50 Hz
Min. switch-on time
0.5 s
Max. duty cycle
99 min
Switch-off delay
10 s
Switch-on delay
1 s
Detection angle horizontal
360 - 360 °
Swivel range sensor, horizontal
0 - 0 °
Swivel range sensor, vertical
0 - 0 °
Response value luminosity
0 - 2000 lx
Max. switching power
2300 W
Suitable for C-load
Nein
Number of switching zones
1
Max. starting current
80 A
Control current
3.478 mA
Substation input
Nein
With alarm function
Nein
Width
88 mm
Height
88 mm
Depth
112 mm
Diameter
88 mm
Built-in depth
63 mm
Built-in diameter
64 mm
Nominal voltage
230 - 230 V
Background monitoring
Nein
With acoustic sensor
Nein
With connection cable
Nein
Connection cable length
0 mm
Movement sensor/presence detector technology
Passive infrared
Ambient temperature
-10 - 35 °C
