Allgemeine Information
Wcd.LS990 wit slagvast klapdeksel
Wcd.LS990 wit slagvast klapdeksel
YESSS-Bestellnummer
3003-7095
Produktcode
LS1520NBFKL
EAN-Code
04011377157149
Produktgruppe
Socket outlet
Marke
Jung
Serie
LS range
Typ
LS1520NBFKL
Produktbeschreibung
Wcd.LS990 wit slagvast klapdeksel
Produktspezifikationen
Model
Socket outlet with protective contact CEE 7/3 (type F)
Number of active contacts (round)
2
Number of active contacts (flat)
0
With signal lamp
Nein
Number of socket outlets switchable
0
Number of phases
1
Imprint/indication
None
Connection type
Push-in clamp
With hinged lid
Ja
With enhanced contact protection
Nein
Label space/information surface
Nein
Colour
White
RAL-number (similar)
1013
Transparent
Nein
Lockable
Nein
Eject-mechanism
Nein
Insulated mounting
Nein
With function lighting
Nein
With orientation lighting
Nein
Overvoltage protection
Nein
Fault current protection
Nein
With miniature fuse
Nein
Mounting method
Flush-mounted
Type of fastening
Mounting with screw
Material
Plastic
Material quality
Thermoplastic
Halogen free
Ja
Surface protection
Other
Surface finishing
Glossy
Anti-bacterial treatment
Nein
With on/off switch
Nein
With loop through function
Nein
Rotated central insert
Nein
Nominal current
16 A
Nominal voltage
250 V
Frequency
50 - 50 Hz
Suitable for degree of protection (IP)
IP44
Device width
70 mm
Device height
70 mm
Device depth
30 mm
Metallic colour
Nein
Compatible with Apple HomeKit
Nein
Compatible with Google Assistant
Nein
Compatible with Amazon Alexa
Nein
IFTTT support available
Nein
For heavy conditions according to VDE
Nein
Number of ports USB-A
0
Number of ports USB-C
0
Max. current rating of USB power supply
0 A
With Wi-Fi signal repeater
Nein
With built-in bluetooth speaker
Nein
Compliant with UK Building Regulations Part M
Ja
Concurrently switching neutral conductor
Nein
Protective contact
Earthing clips
Number of active contacts (square)
0
Number of loop throughs
1
Number of socket outlets
1
Socket outlets phase-separated
Nein
Mounting direction
Vertical
Assembly arrangement
Basic element with central cover plate
