FLEXILED 4IL23S/A 840 WIT LW1195/295-LED-Ingelegd armatuur 4000K 26W s
- 3110-1214
- |
- 3122383
0 stück
lagernd
Sie haben noch kein Konto? Account erstellen
-
Über 6.000 Produkte auf Lager
-
Bestellen Sie vor 17:00 Uhr und erhalten Sie Ihre Bestellung am nächsten Werktag!
- Benötigen Sie Hilfe? Rufen Sie 0800 - 5011 an oder kontaktieren Sie uns per E-Mail unter [email protected]
Allgemeine Information
FLEXILED 4IL23S/A 840 WIT LW1195/295-LED-Ingelegd armatuur 4000K 26W s
FLEXILED 4IL23S/A 840 WIT LW1195/295-LED-Ingelegd armatuur 4000K 26W s
YESSS-Bestellnummer
3110-1214
Produktcode
3122383
EAN-Code
04046075198194
Produktgruppe
Ceiling-/wall luminaire
Marke
Performance in Lighting
Serie
FLEXILED
Typ
3122383
Produktbeschreibung
Inbouwarmaturen voor binnen, bestaande uit: Behuizing van vormstabiel 1,0 mm plaatstaal. Slagvaste, afdrukbestendige poedercoating. Witte reflector zorgt voor maximaal rendement en hoog visueel comfort. UGR <19 voor alle lichtstromen. Betrouwbaar en onderhoudsarm 50.000u L80B10. Kleurtolerantie volgens MacAdam ≤3 SDCM. 2 vermogensniveaus instelbaar. Incl. voorgemonteerde installatieveer. Uitvoering in speciale kleuren op verzoek leverbaar
Produktspezifikationen
Suitable for suspended mounting
Nein
Suitable for ceiling mounting
Ja
Suitable for built-in mounting
Ja
Suitable for surface mounting
Nein
Suitable for light line configuration
Nein
Suitable for workplace according to EN 12464-1
Nein
Lamp type
LED exchangeable
With light source
Ja
Suitable for number of light sources
1
Housing material
Steel
Housing colour
White
Type of grid
White
Voltage type
AC
Nominal voltage
220 - 240 V
Type of control gear
LED operating device current-controlled
With control gear
Ja
Dimming 0-10 V
Nein
Dimming 1-10 V
Nein
Dimming DALI
Nein
Dimming DMX
Nein
Dimming DSI
Nein
Dimming potentiometer (integrated)
Nein
Dimming manufacturer's proprietary system
Nein
Dimming mains voltage modulation
Nein
Dimming phase cut-off (trailing edge)
Nein
Dimming phase cut-on (leading edge)
Nein
Dimming programmable
Nein
Dimming RF
Nein
Dimming Touch and Dim
Nein
Dimming Zigbee
Nein
Dimming with push-button
Nein
Light distributor
None
Light distribution
Symmetric
Beam angle
41-80° - Wide beam
Light outlet
Direct
Rated lifetime L70/B50 at 25 °C
99800 h
Degree of protection (NEMA)
1
Impact strength
IK05
Protection class according to IEC 61140
I
Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24
Nein
Rated ambient temperature according to IEC 62722-2-1
10 - 40 °C
Suitable for emergency lighting
Nein
With movement sensor
Nein
With light sensor
Nein
Covering of the luminaire with thermally insulating material possible
Nein
With air slots
Nein
Filament test according to IEC 60695-2-11
650 °C - 30 s
Suitable for lamp power
15 - 23 W
Max. system power
26 W
Colour of light
White
Colour temperature
4000 - 4000 K
Colour rendering index CRI
80-89
Power factor
0.9
Width
295 mm
Height/depth
12 mm
Length
1195 mm
Built-in length
1180 mm
Built-in width
130 mm
Built-in height/depth
80 mm
Type of wiring
Suitable for loop-through wiring
Number of poles
3
Conductor cross section
1.5 mm²
Connection type
Push-in clamp
Surface protection housing
Powder coating
Nominal current
108 - 118 mA
Exchangeable control gear
Ja
Dimming DALI-2
Nein
Colour consistency (McAdam ellipse)
SDCM3
Lumen maintenance at median useful life of 35,000 h at 25 °C ambient (tq)
79 %
Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq)
70 %
Lumen maintenance at median useful life of 75,000 h at 25 °C ambient (tq)
55 %
Failure rate at median useful life of 35,000 h at 25 °C ambient (tq)
0.8 %
Failure rate at median useful life of 50,000 h at 25 °C ambient (tq)
1 %
Failure rate at median useful life of 75,000 h at 25 °C ambient (tq)
1.2 %
Max. number of luminaires per miniature circuit breaker B16 (MCB)
0
Max. number of luminaires per miniature circuit breaker C16 (MCB)
0
Flickering value Pst LM
0.7
Stroboscope effect value SVM
0.4
Constant light output (CLO)
Nein
Photobiological safety according to EN 62471
RG0
Unified Glare Ratio (UGR)
19
Colour of light adjustable
No
Luminous flux adjustable
Positions
Beam angle adjustable
No
Operation by Bluetooth
Nein
Compatible with Apple HomeKit
Nein
Compatible with Google Assistant
Nein
Compatible with Amazon Alexa
Nein
IFTTT support available
Nein
Suitable for wall mounting
Nein
Energy efficiency class of the light source according to EU regulation 2019/2015
B
Compatible with Casambi
Nein
Meets min. EIA lifetime criterion L90 (at 50,000 hours at tq = 25 °C)
Nein
Dimmable
Nein
Luminaire efficacy
162 - 167 lm/W
Rated luminous flux according to IEC 62722-2- 1
2840 - 4210 lm
With presence detector
Nein
Containing product according to 2019/2020/EU
Ja
Degree of protection (IP), rear side
IP20
Degree of protection (IP), front side
IP20
Emergency power supply system
None
Emergency function monitoring system
None
Connectable conductor cross section
1 - 2.5 mm²
Ball-proof according to DIN 18032-3
Nein
Suitable for clamp-mounting
Nein
With mounting material
Ja
With switch
Nein
