SUN 18W LED circular panel, IP20, 225mm, White, 3000K

  • 3050-8715
  • |
  • R225LEDC30N-01
2 stück lagernd
Zum Bestellen anmelden
Sie haben noch kein Konto? Account erstellen
  • Products Über 6.000 Produkte auf Lager
  • Bestellen Sie vor 17:00 Uhr und erhalten Sie Ihre Bestellung am nächsten Werktag!
  • Benötigen Sie Hilfe? Rufen Sie 0800 - 5011 an oder kontaktieren Sie uns per E-Mail unter [email protected]

Allgemeine Information

SUN 18W LED circular panel, IP20, 225mm, White, 3000K SUN 18W LED circular panel, IP20, 225mm, White, 3000K
YESSS-Bestellnummer
3050-8715
Produktcode
R225LEDC30N-01
EAN-Code
05391370071697
Produktgruppe
Ceiling-/wall luminaire
Marke
Robus
Serie
Downlights
Typ
Sun

Produktbeschreibung

* The SUN circular LED panel is ROBUS's solotion to larger scale downlights complete with plug and play driver and 1m flex for ease of install * The range offer energy efficient LED replacement for up to 2x26W PL downlights * Suitable for use in offices, health cares and hospitals, shops, hotels, restaurants, schools and universities with it's die cast aluminium body with polycarbonate diffuser * Suitable for switching by PIR, Microwave or Photocell

Produktspezifikationen

Suitable for suspended mounting
Nein
Lamp type
LED not exchangeable
With light source
Ja
Housing material
Aluminium
Housing colour
White
Material cover
Plastic, opal
Voltage type
AC
Nominal voltage
220 - 240 V
Type of control gear
LED operating device current-controlled
With control gear
Ja
Dimming 0-10 V
Nein
Dimming 1-10 V
Nein
Dimming DALI
Nein
Dimming DMX
Nein
Dimming DSI
Nein
Dimming potentiometer (integrated)
Nein
Dimming manufacturer's proprietary system
Nein
Dimming mains voltage modulation
Nein
Dimming phase cut-off (trailing edge)
Nein
Dimming phase cut-on (leading edge)
Nein
Dimming programmable
Nein
Dimming RF
Nein
Dimming Touch and Dim
Nein
Dimming Zigbee
Nein
Dimming with push-button
Nein
Beam angle
> 80° - Extreme wide beam
Rated lifetime L70/B50 at 25 °C
30000 h
Impact strength
IK08
Protection class according to IEC 61140
II
Rated ambient temperature according to IEC 62722-2-1
-20 - 40 °C
With movement sensor
Nein
With light sensor
Nein
Max. system power
19.9 W
Colour of light
White
Colour temperature
3000 - 3000 K
Colour rendering index CRI
80-89
Power factor
0.95
Height/depth
25 mm
Outer diameter
225 mm
Built-in height/depth
22.5 mm
Built-in diameter
210 mm
Nominal current
90 - 90 mA
Unified Glare Ratio (UGR)
27.7
Colour of light adjustable
No
Operation by Bluetooth
Nein
