Bewegingsmelder voor buiten PIRA-T, 1xlicht, wandmontage, 180°, 10m, I

  • 3135-8723
  • |
  • 1030206
96 stück lagernd
Zum Bestellen anmelden
Sie haben noch kein Konto? Account erstellen
  • Products Über 6.000 Produkte auf Lager
  • Bestellen Sie vor 17:00 Uhr und erhalten Sie Ihre Bestellung am nächsten Werktag!
  • Benötigen Sie Hilfe? Rufen Sie 0800 - 5011 an oder kontaktieren Sie uns per E-Mail unter [email protected]

Allgemeine Information

Bewegingsmelder voor buiten PIRA-T, 1xlicht, wandmontage, 180°, 10m, I Bewegingsmelder voor buiten PIRA-T, 1xlicht, wandmontage, 180°, 10m, I
YESSS-Bestellnummer
3135-8723
Produktcode
1030206
EAN-Code
04003468102190
Produktgruppe
Movement sensor/presence detector complete
Marke
Theben
Serie
PIRA
Typ
PIRA TO AP

Produktbeschreibung

Bewegingsmelder (PIR) voor wandmontage buiten, halfrond detectiebereik 180°, 10 m bij 2 m montagehoogte, 1 kanaal Licht (230 V relais), automatische bewegings- en helderheidsafhankelijke regeling van de verlichting, mixlichtmeting, werking als volautomatische, helderheidsschakelwaarde instelbaar via potentiometer, nalooptijd instelbaar via potentiometer, direct klaar voor gebruik door fabrieks-voorinstelling (helderheidsschakelwaarde 100 lux, nalooptijd 2 min.)

Produktspezifikationen

Model
Movement sensor
Constant light control
Nein
HVAC-control
Nein
Forced switch on
Nein
Forced switch off
Nein
Animal zone
Nein
Creep-under protection
Nein
Networkable
Nein
Scan angle
150 °
Optimum mounting height
2 m
Staircase light controller
Nein
Bridging switch
Nein
Max. reach sideways
10 m
Max. reach frontally
10 m
Diameter reach on floor
10 m
Suitable for wireless transmission
Nein
Remote operation
Nein
With remote control
Nein
Response value sensitivity adjustable
Nein
Response value luminosity adjustable
Ja
With signal unit
Nein
Teach-function for response value luminosity
Nein
Suitable for ceiling mounting
Nein
Dim function with dimmer basic element
Nein
Mounting method
Surface mounted
Connection type
Screwed terminal
Material
Plastic
Material quality
Thermoplastic
Halogen free
Nein
Surface protection
Untreated
Surface finishing
matt
Anti-bacterial treatment
Nein
Colour
White
RAL-number (similar)
9010
Transparent
Nein
Degree of protection (IP)
IP55
Impact strength
IK04
Voltage type
AC
Frequency
50 - 50 Hz
Min. switch-on time
5 s
Max. duty cycle
15 min
Switch-off delay
900 s
Detection angle horizontal
0 - 180 °
Swivel range sensor, horizontal
0 - 90 °
Swivel range sensor, vertical
0 - 35 °
Response value luminosity
5 - 1000 lx
Max. switching power
1000 W
Suitable for C-load
Ja
Substation input
Nein
With alarm function
Nein
Width
78 mm
Height
80 mm
Depth
86 mm
Max. switching power LED
200 W
Compatible with Apple HomeKit
Nein
Compatible with Google Assistant
Nein
Compatible with Amazon Alexa
Nein
IFTTT support available
Nein
Nominal voltage
230 - 230 V
Suitable for wall mounting
Ja
Background monitoring
Nein
With acoustic sensor
Nein
With connection cable
Nein
Ceiling built-in mounting without installation box
Nein
Compatible with Casambi
Nein
Movement sensor/presence detector technology
Passive infrared
Ambient temperature
-20 - 40 °C
