Allgemeine Information
UNITRONIC BUS EIB 2x2x0.8 - 100 MTR
UNITRONIC BUS EIB 2x2x0.8 - 100 MTR
YESSS-Bestellnummer
3081-3303
Produktcode
2170240
EAN-Code
04044774750224
Produktgruppe
Data and communication cable
Marke
UNITRONIC
Serie
Bus system EIB
Typ
UNITRONIC BUS EIB / KNX
Produktbeschreibung
Produktspezifikationen
Conductor surface
Bare
Nominal cross section conductor
0.8 mm²
Conductor category
Class 1 = solid
Number of cores
4
Number of stranding elements
2
Stranding element
Pairs
Material core insulation
Polyvinyl chloride (PVC)
Core identification
Colour
Screen over stranding element
Foil
Stranding
Bundle
Screen over stranding
Foil
Longitudinal water blocking cable
Nein
Radial water blocking cable
Nein
Material outer sheath
Polyvinyl chloride (PVC)
Colour outer sheath
Green
Reaction-to-fire according to EN 13501-6: Class
Eca
Halogen free according to EN IEC 60754-2
Nein
Low smoke according to EN IEC 61034-2
Nein
Oil resistant according to EN IEC 60811-404
Nein
Outer diameter approximate
6.6 mm
Min. permitted bending radius, stationary application/permanent installation
33 mm
Permitted cable outer temperature after assembling without vibration
-30 - 70 °C
Suitable for underground installation
Nein
Conductor material
Copper
Core identification according to HD 308 S2
Nein
Armouring/reinforcement
Armouring tape
Material armouring
Aluminium
Cable geometry
Round
Certified for shipboard application
Nein
Suitable as telephone cable
Nein
Suitable as computer data cable
Ja
Suitable as signalling cable
Ja
Weight
54 kg/km
Drain wire
Nein
Characteristic impedance
85 Ohm
With rodent protection
Nein
Flame retardant according to IEC 60332-1-2
Nein
Flame retardant according to IEC 60332-3-21 (Cat A F/R)
Nein
Flame retardant according to IEC 60332-3-22 (Cat A)
Nein
Flame retardant according to IEC 60332-3-23 (Cat B)
Nein
Flame retardant according to IEC 60332-3-24 (Cat C)
Nein
Flame retardant according to IEC 60332-3-25 (Cat D)
Nein
Halogen free according to EN IEC 60754-1
Nein
Halogen free according to EN IEC 60754-3
Nein
Circuit integrity according to IEC 60331-23
Nein
Suitable for use as security alarm cable
Nein
With rip cord
Nein
