Installatieautomaat 13A, 10kA, 3 polig+N, D kar.

Add to selection
General information
Ordercode YESSS
2082-2074
Product code
2CDS273103R0131
EAN code
04016779663403
Product group
Miniature circuit breaker (MCB)
Brand
ABB Componenten
Serie
System pro M compact
Type
S203M-D13NA
Installatieautomaat 13A, 10kA, 3 polig+N, D kar. Installatieautomaat 13A, 10kA, 3 polig+N, D kar.
STOCK
IN STOCK
0 piece
Product description

De S203M-D13NA uit de System pro M compact-serie is een installatieautomaat voor betrouwbare bescherming tegen overbelasting en kortsluiting in verdeelinrichtingen. Met 3 polen + N en D-karakteristiek schakelt hij selectief bij hoge inschakelstromen, ideaal voor toepassingen met zware aanloop. De nominale stroom van 13 A en het schakelvermogen tot 10 kA bieden zekerheid in residentiële, commerciële en industriële omgevingen.Deze installatieautomaat is stroombegrenzend voor lagere foutenergie en minder thermische belasting op de installatie. Twee uitschakelmechanismen – vertraagde thermische beveiliging en een elektromagnetische kortsluitbeveiliging – zorgen voor snelle, nauwkeurige uitschakeling. Conformiteit met IEC/EN 60898-1 en 60947-2 waarborgt brede toepasbaarheid. Onderbouw montage van een hulpcontact bespaart tot 50% ruimte, en de System pro M compact-range biedt aansluitende configuratieopties waar nodig.

Product specifications
Release characteristic
D
Number of poles (total)
4
Number of protected poles
3
Rated current
13 A
Rated voltage
400 V
Rated insulation voltage Ui
440 V
Rated impulse withstand voltage Uimp
4 kV
Voltage type
AC
Frequency
50 - 60 Hz
Current limiting class
3
Concurrently switching neutral conductor
Yes
Overvoltage category
3
Pollution degree
3
Additional equipment possible
Yes
Width in number of modular spacings
4
Built-in depth
69 mm
Degree of protection (IP)
IP20
Ambient temperature during operating
-25 - 55 °C
Connectable conductor cross section multi-wired
0.75 - 25 mm²
Connectable conductor cross section solid-core
0.75 - 35 mm²
Flush-mounted installation
No
Explosion-proof
No
Power loss
8.8 W
