UPS Eaton
Add to selection
General information
Ordercode YESSS
3059-8773
Product code
9PX3000IRTN-L
EAN code
00743172105851
Product group
UPS
Brand
Eaton
Product specifications
Input voltage
100 - 276 V
Primary frequency
40 - 70 Hz
Number of phases primary
1
Output voltage
200 - 240 V
Secondary frequency
50 - 60 Hz
Output effective power
2400 W
Output apparent power
3000 VA
Number of phases secondary
1
SNMP
Yes
Voltage type
AC
Height
86.5 mm
Width
440 mm
Depth
605 mm
Bridging time full load
20.5 min
Weight
22.9 kg
Suitable for network-management
Yes
USV- technology
Online
Construction type
482.6 mm (19 inch) device
Max. voltage distortion output (linear load)
3 %
Output power factor
1
Overall efficiency
94 %
Efficiency in eco-mode
98 %
Potential free switch contact
Yes
Auto shut down function
Yes
Input connection
C20
Number of output connections C13
8
Number of output connections C19
2
Number of output connections fixed connection
0
USB interface
No
With communication interface RS-232
No
Modular
No
Power consumption
180 W
Product information
