Industriële beeldmultimeter met IGM™

Add to selection
General information
Ordercode YESSS
3109-8291
Product code
DM286
EAN code
00793950382868
Product group
Multimeter
Brand
FLIR
Serie
Multimeter
Type
DM286
Industriële beeldmultimeter met IGM™ Industriële beeldmultimeter met IGM™
STOCK
IN STOCK
0 piece
Product description


De nieuwe FLIR DM286  industriële beeldvormingsmultimeter biedt technici een tool met de volgende generatie FLIR-test- en meetmogelijkheden, waardoor gebruikers veilige, nauwkeurige en efficiënte inspecties kunnen uitvoeren.
Door middel van IGM™ (Infrared Guided Measurement) worden gebruikers in staat gesteld om eventuele gevaren veilig te identificeren, voordat er ooit contact is gemaakt.

Kenmerken:

  • IR beeld resolutie (160 × 120 pixels)
  • 35% helderder 2,8-inch scherm
  • Instellingen voor hoge/gemiddelde/lage helderheid
  • Opslag voor 30.000 afbeeldingen
  • MSX®
  • Thermal Studio software
  • 2MP visuele camera
  • Video-opname
  • 2 - Li-Po-batterijen met lange levensduur, geen AA-cellen
  • Bluetooth-integratie® met de nieuwe METERLiNK App

Wat is in de doos:

  • 1 FLIR DM286 True RMS-multimeter
  • 1

    Product specifications
    Indication
    Graphic
    Multiple display
    Yes
    Measuring range selection
    Manual/automatic
    Max. voltage measuring range AC
    1000 V
    Lowest resolution, AC voltage
    1 mV
    Max. voltage measuring range DC
    1000 V
    Lowest resolution, DC voltage
    1 mV
    Max. current measuring range, AC
    10 A
    Lowest resolution, AC current
    10 µA
    Max. current measuring range, DC
    10 A
    Lowest resolution, DC current
    10 µA
    Max. resistance measuring range
    6000 M Ohm
    Milliohm measurement with 4 wire technique (Kelvin connection)
    No
    Temperature measurement TC
    Yes
    Max. temperature measuring range
    400 °C
    Lowest resolution temperature
    0.1 °C
    Capacitance measurement
    Yes
    Max. capacitance measuring range
    10 µF
    Frequency measurement
    Yes
    Max. frequency measuring range
    100 kHz
    Lowest resolution, frequency
    0.01 Hz
    Resistance test/diode test
    Yes
    Nominal test voltage 10 V
    No
    Nominal test voltage 50 V
    No
    Nominal test voltage 100 V
    No
    Nominal test voltage 250 V
    No
    Nominal test voltage 500 V
    No
    Nominal test voltage 1000 V
    No
    Cable length measurement
    No
    Cable symmetry testing for two wire connections a-b-E
    No
    Power and energy measurement
    No
    Harmonics analysis/power quality
    No
    With decibel measurement (dB)
    No
    Relative value measurement
    Yes
    Inductance measurement
    No
    With conductivity measurement
    No
    Continuity test
    Yes
    Data hold
    Yes
    Max. value storage
    Yes
    Min. value storage
    Yes
    Peak value memory
    Yes
    True RMS measurement
    Yes
    Duty cycle measurements
    No
    Rotational speed measuring
    No
    Measured value memory
    Yes
    Bluetooth interface
    Yes
    IR interface
    Yes
    Measuring circuit category
    CAT IV
    Max. voltage measuring circuit category
    600 V
    With display backlight
    Yes
    Temperature measurement
    Yes
    Degree of protection (IP)
    IP40
    Scaling bar graph linear
    Yes
    Scaling bar graph logarithmic
    Yes
    Current supply
    Battery/mains
    more specifications
