General information
Afdekraam 5-voudig verticaal, tekstveld, A.1, titaan
Afdekraam 5-voudig verticaal, tekstveld, A.1, titaan
Ordercode YESSS
3144-4379
Product code
WAD6503TA
EAN code
03250610067017
Product group
Cover frame for domestic switching devices
Brand
Hager
Serie
A.1
Type
Afdekraam
Product description
Afdekraam 5-voudig verticaal, tekstveld, A.1, titaan
Product specifications
Number of units
5
Mounting direction
Vertical
Number of device inserts horizontal
0
Number of device inserts vertical
5
Number of modules horizontal (module system)
0
Number of modules vertical (module system)
5
With mounting grid
No
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Titanium
RAL-number (similar)
9006
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP20
Impact strength
IK05
Type of fastening
Clamp mounting
Width
365.5 mm
Height
81.5 mm
Depth
10 mm
Built-in width
0 mm
Built-in height
0 mm
Diameter bore hole (opening)
0 mm
Flush-mounted installation
Yes
Anti-bacterial treatment
No
