General information
Leddriver constante stroom, CC 250-1000mA 50W 1CH Lumiko Easy
Leddriver constante stroom, CC 250-1000mA 50W 1CH Lumiko Easy
Ordercode YESSS
3102-5880
Product code
860662
EAN code
08716643076280
Product group
LED driver
Brand
Lumiko
Serie
Leddriver constante stroom, Lumiko
Type
LD-CC50W-1000-LE
Product description
Leddriver constante stroom, CC 250-1000mA 50W 1CH Lumiko Easy
Product specifications
Suitable for outdoor use
No
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DSI
No
Dimming DMX
No
Dimming potentiometer (integrated)
No
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
Yes
Dimming mains voltage modulation
No
Dimming phase cut-off (trailing edge)
No
Dimming phase cut-on (leading edge)
No
Dimming programmable
Yes
Dimming RF
Yes
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
Housing
Plastic housing
Suitable for constant current
Yes
Suitable for constant voltage
No
Output voltage
8 - 52 V
Output current
250 - 1000 mA
Suitable for DC-voltage (primary side)
No
Output power
1 - 50 W
Degree of protection (IP)
IP20
Protection class according to IEC 61140
II
Length
210 mm
Width
50 mm
Height
32 mm
Constant light output (CLO)
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Operation by Bluetooth
Yes
Compatible with Casambi
No
Dimmable
Yes
Dimming DALI-2
No
Input voltage
200 - 240 V
Frequency input voltage
50 - 60 Hz
Independently operating
Yes
Overload protection
Yes
Overtemperature protection
Yes
Short-circuit protected
Yes
Dimming D4i
No
Emergency power supply system
None
Ambient temperature
-20 - 45 °C
Number of colour channels
1
DIN-rail mounting
No
Operation by Matter
No
