Led driver constante Stroom 30W, 1-10V, 100-1400mA
- 0415-3372
- |
- 876809
1
piece
in stock
Don’t have an account? Request account
-
Over 6.000 products in stock
-
Order before 17:00 and receive your order the next working day!
- Need help? Call --- --- or contact us via email at [email protected]
General information
Led driver constante Stroom 30W, 1-10V, 100-1400mA
Led driver constante Stroom 30W, 1-10V, 100-1400mA
Ordercode YESSS
0415-3372
Product code
876809
EAN code
08716643036932
Product group
LED driver
Brand
Lumiko
Serie
Leddriver universeel, 1-10V
Type
DRV-30W-INST
Product description
Led driver constante Stroom 30W, 1-10V, 100-1400mA
Product specifications
Suitable for outdoor use
No
Dimming 0-10 V
Yes
Dimming 1-10 V
Yes
Dimming DALI
No
Dimming DSI
No
Dimming DMX
No
Dimming potentiometer (integrated)
Yes
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off (trailing edge)
No
Dimming phase cut-on (leading edge)
No
Dimming programmable
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
Yes
Housing
Plastic housing
Suitable for constant current
Yes
Suitable for constant voltage
No
Output voltage
6 - 42 V
Output current
100 - 1400 mA
Suitable for DC-voltage (primary side)
No
Output power
1 - 30 W
Degree of protection (IP)
IP20
Protection class according to IEC 61140
II
Length
110 mm
Width
52 mm
Height
23.5 mm
Constant light output (CLO)
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Operation by Bluetooth
No
Compatible with Casambi
No
Dimmable
Yes
Dimming DALI-2
No
Input voltage
180 - 240 V
Frequency input voltage
50 - 60 Hz
Independently operating
Yes
PWM modulation
No
Overload protection
Yes
Overtemperature protection
Yes
Short-circuit protected
Yes
Dimming D4i
No
Efficiency
88 %
Mains surge immunity (common mode, L/N-Ground)
6 kV
Mains surge immunity (differential mode, L-N)
2 kV
Emergency power supply system
None
Ambient temperature
-20 - 45 °C
Max. number of luminaires per miniature circuit breaker B16 (MCB)
94
Max. number of luminaires per miniature circuit breaker C16 (MCB)
94
Driver lifetime
50000 h
Number of colour channels
1
DIN-rail mounting
No
Operation by Matter
No
