Model
Standard electric strike
Assembly arrangement
Frame part
Shape of strike plate
Flat
With mechanical unlocking
Yes
Opening direction according to DIN
Left/right
Type of latch
Radius latch
Construction type
Symmetric
Built-in position
Vertical
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Adjustable electric strike latch
No
Adjustable electric strike
No
Adjustable strike plate
No
Latch guide integrated
No
Unlocking method
Standard model
Continuous operation (100 % ED)
No
Suitable for fire protection door
No
Suitable for smoke protection door
No
Material strike plate
Stainless steel
Basic colour of strike plate
Silver
Length of strike plate
250 mm
Width of strike plate
25 mm
Thickness of strike plate
3 mm
For bolt switch contact prepared
Yes
Utility category according to EN 14846
Other
Lasting functionability according to EN 14846
Other
Mass of door, clamp force according to EN 14846
Other
Suitable for fire- and smoke protection doors according to EN 14846
Other
Safety - personal protection according to EN 14846
Other
Environmental condition according to EN 14846
Other
Safety - burglary protection according to EN 14846
0
Protective effect with regard to electrical mode of operation acc. to EN 14846
0
Protective effect with regard to electrical tampering according to EN 14846
2
Drill hole offset by 1 mm
No
Operating principle
Working current
Electrical connection re-pluggable
Yes
Electrical connection clampable/pluggable
Yes
Connection cable length
0 m
Deadbolt throw (size)
0 mm
Resistance against break up
3230 N
Adjustment range latch adjustment
2.5 mm
Operating temperature
-15 - 40 °C
Tolerance rated operating voltage
+/- 10 %
Explosion safety category for gas
None
Explosion safety category for dust
None
