RENZO XCHANGE 10W 3/4/65K
Add to selection
General information
Ordercode YESSS
3127-5081
Product code
MM12351
EAN code
04892657123517
Product group
Ceiling-/wall luminaire
Brand
Megaman
Serie
RENZO
Type
LED Geïntegreerd
RENZO XCHANGE 10W 3/4/65K
RENZO XCHANGE 10W 3/4/65K
STOCK
IN STOCK
0
piece
Product description
Schakelbare Kelvin: via een ingebouwde switch te schakelen tussen 3000K/1150Lm (warmwit) ,4000K/1200Lm (koelwit) en 6500K/1200Lm (daglicht).Naar keuze achteraf ook nog uit te rusten met bewegingssensor (MM10286) en/of noodvoedingsunit (MM12279).
Product specifications
Suitable for suspended mounting
No
Suitable for ceiling mounting
Yes
Suitable for built-in mounting
No
Suitable for surface mounting
Yes
Suitable for light line configuration
No
Suitable for workplace according to EN 12464-1
No
Lamp type
LED exchangeable
With light source
Yes
Housing material
Plastic
Housing colour
White
Material cover
Plastic matt/satinized
Type of grid
None
Voltage type
AC/DC
Nominal voltage
220 - 240 V
Type of control gear
Not required
With control gear
Yes
Light distributor
Other
Light distribution
Symmetric
Beam angle
> 80° - Extreme wide beam
Light outlet
Direct
Rated lifetime L70/B50 at 25 °C
100000 h
Impact strength
IK05
Protection class according to IEC 61140
II
Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24
No
Rated ambient temperature according to IEC 62722-2-1
-30 - 40 °C
Suitable for emergency lighting
Yes
With movement sensor
No
With light sensor
No
Covering of the luminaire with thermally insulating material possible
No
With air slots
No
Filament test according to IEC 60695-2-11
650 °C - 30 s
Max. system power
10 W
Colour of light
White
Colour temperature
3000 - 6500 K
Colour rendering index CRI
80-89
Power factor
0.9
Height/depth
100 mm
Outer diameter
280 mm
Type of wiring
Suitable for loop-through wiring
Number of poles
3
Connection type
Push-in clamp
Surface protection housing
Untreated
Nominal current
50 - 50 mA
Exchangeable control gear
Yes
Colour consistency (McAdam ellipse)
SDCM6
Lumen maintenance at median useful life of 35,000 h at 25 °C ambient (tq)
100 %
Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq)
100 %
Lumen maintenance at median useful life of 75,000 h at 25 °C ambient (tq)
90 %
Failure rate at median useful life of 35,000 h at 25 °C ambient (tq)
10 %
Failure rate at median useful life of 50,000 h at 25 °C ambient (tq)
2 %
Failure rate at median useful life of 75,000 h at 25 °C ambient (tq)
3 %
Max. number of luminaires per miniature circuit breaker B16 (MCB)
84
Max. number of luminaires per miniature circuit breaker C16 (MCB)
99
Flickering value Pst LM
1
Stroboscope effect value SVM
0.4
Constant light output (CLO)
No
Photobiological safety according to EN 62471
RG0
Colour of light adjustable
Positions
Luminous flux adjustable
No
Beam angle adjustable
No
Operation by Bluetooth
No
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Suitable for wall mounting
Yes
Energy efficiency class of the light source according to EU regulation 2019/2015
D
Compatible with Casambi
No
Dimmable
No
Luminaire efficacy
115 - 120 lm/W
Rated luminous flux according to IEC 62722-2- 1
1150 - 1200 lm
With presence detector
No
Containing product according to 2019/2020/EU
Yes
Total harmonic distortion (THD)
20 %
Degree of protection (IP), rear side
IP44
Degree of protection (IP), front side
IP44
Max. number of luminaires per miniature circuit breaker C10 (MCB)
85
Emergency power supply system
None
Emergency function monitoring system
None
Connectable conductor cross section
1.5 - 2.5 mm²
Suitable for clamp-mounting
No
With mounting material
Yes
With switch
No
With connection cord and plug
No
