Movement sensor/presence detector complete Merten by Schneider Electric
Add to selection
General information
Ordercode YESSS
3132-4311
Product code
MEG5628-3160
EAN code
04042811184650
Product group
Movement sensor/presence detector complete
Brand
Merten by Schneider Electric
Product specifications
Model
Movement sensor
Constant light control
No
HVAC-control
No
Forced switch on
No
Forced switch off
No
Animal zone
No
Creep-under protection
Yes
Networkable
No
Scan angle
220 °
Optimum mounting height
2.5 m
Staircase light controller
Yes
Bridging switch
No
Max. reach sideways
14 m
Max. presence range
50 m²
Max. reach frontally
16 m
Diameter reach on floor
28 m
Suitable for wireless transmission
Yes
Remote operation
Yes
With remote control
No
Response value sensitivity adjustable
Yes
Response value luminosity adjustable
Yes
With signal unit
No
Teach-function for response value luminosity
No
Suitable for ceiling mounting
Yes
Dim function with dimmer basic element
No
Mounting method
Surface mounted
Connection type
Push-in clamp
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Glossy
Anti-bacterial treatment
No
Colour
Aluminium
Transparent
No
Degree of protection (IP)
IP55
Impact strength
IK02
Voltage type
AC
Frequency
50 - 50 Hz
Min. switch-on time
1 s
Max. duty cycle
8 min
Switch-off delay
480 s
Switching-on delay
0 s
Detection angle horizontal
0 - 220 °
Pivoting range sensor, horizontal
-12 - 12 °
Pivoting range sensor, vertical
-24 - 9 °
Response value luminosity
3 - 1000 lx
Max. switching power
2000 W
Suitable for C-load
Yes
Number of switching zones
112
Max. starting current
16 A
Min. starting current
0 A
Substation input
No
With alarm function
No
Width
93 mm
Height
151 mm
Depth
71 mm
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
