Velox 2.0 Type 50 - 4x 230V RA + 8x
- 3016-3096
- |
- 33.70.006
0
piece
in stock
Don’t have an account? Request account
-
Over 6.000 products in stock
-
Order before 17:00 and receive your order the next working day!
- Need help? Call --- --- or contact us via email at [email protected]
General information
Velox 2.0 Type 50 - 4x 230V RA + 8x
Velox 2.0 Type 50 - 4x 230V RA + 8x RJ45 uitsp. - deksel - 4mm inleg -
Ordercode YESSS
3016-3096
Product code
33.70.006
EAN code
08719322730022
Product group
Device installation insert for subfloor installation
Brand
O.C.S. Velox®
Serie
Vloerdozen
Type
Velox®
Product description
Deze instortvloerdoos is de meest verkochte OCS VELOX© variant. We leveren een complete vloerdoos onder een artikelnummer. Alle OCS VELOX© vloerdozen worden in Nederland geproduceerd. Deze uitvoering heeft de volgende eigenschappen:
- Stevige sendzimir behuizing.
- Geringe instortdiepte van 50 mm.
- Compleet voorbedraad geleverd met 4x 230V RA.
- Gescheiden 8v datapaneel, geschikt voor de meeste dataconnectoren.
- RAL7024 kunststof klapdeksel met 4 mm inleg, geschikt voor o.a. tapijt. Deksel sluit met aangesloten kabels.
- Gebruikte kunststoffen zijn halogeenvrij UL94-V0 vlamdovend. Vloerdoos voldoet aan strengste veiligheidseisen voor publieke ruimte
Product specifications
Cover model
Square
Suitable for wet cleaning
No
Suitable for subfloor duct
No
Suitable for hollow floor
No
Suitable for double floor built-in
No
Number of device cups
12
With opening carpeting
Yes
Depth of flooring recess
3 mm
Protective frame carpeting
Yes
Min. built-in depth
51.5 mm
Colour
Grey
RAL-number
7024
Length built-in dimension
282 mm
Width built-in dimension
252 mm
Number of socket outlets with protective contact CEE 7/3 (type F)
4
Number of socket outlets British Standard BS 1363
0
Number of inlets
18
With cable outlet in cover
Yes
Housing material
Steel
Surface protection housing
Galvanised
Material cover
Plastic
Surface protection cover
Untreated
Surface treatment cover
Untreated
Suitable for indoor installation
Yes
Suitable for outdoor installation
No
Suitable for concrete installation
Yes
Suitable for floors in computer rooms
No
Number of CEE socket outlets (IEC 60309) 16 A / 400 V / 5P (1, 2, 3, N, PE)
0
Number of CEE socket outlets (IEC 60309) 32 A / 400 V / 5P (1, 2, 3, N, PE)
0
Lockable cover
No
Outer length
252 mm
Outer width
252 mm
Degree of protection (IP) when in use (cable outlet open)
IP20
Degree of protection (IP) when not in use (cable outlet closed)
IP20
Number of socket outlets with protective contact CEE 7/5 (type E)
0
Number of data outlet openings
8
Height data outlet opening
19.6 mm
Width data outlet opening
15 mm
