Potentiaalvereffeningsrail voor buiten 50x5mm Roestvrij staal A2 1.430
- 0031-9516
- |
- 5015111
9
piece
in stock
Don’t have an account? Request account
-
Over 6.000 products in stock
-
Order before 17:00 and receive your order the next working day!
- Need help? Call --- --- or contact us via email at [email protected]
General information
Potentiaalvereffeningsrail voor buiten 50x5mm Roestvrij staal A2 1.430
Potentiaalvereffeningsrail voor buiten 50x5mm Roestvrij staal A2 1.430
Ordercode YESSS
0031-9516
Product code
5015111
EAN code
04012195959427
Product group
Equipotential bonding bar
Brand
OBO
Type
1809 A
Product description
Potentiaalvereffeningsrail voor de potentiaalvereffening volgens DIN VDE 0100-410/-540 en bliksembeveiligingspotentiaalvereffening volgens DIN VDE 0185-305• Afdekkap en voetplaat van Polystyreen• Kleur: zwart, UV-bestendig• Bouten en bruggen van roestvast staal• Bliksemstroombestendig 50 kA (10/350)Aansluitmogelijkheden:• 7 één- of meeraderige leidingen tot 25 mm² of soepele kabels tot 16 mm²• 1 Ronde geleider Rd 8-10• 1 Platte geleider tot FL 30 of ronde geleider Rd 8-10
Product specifications
Construction type
Surface mounting fix
Model
With covering cap
Insulator
Yes
Height
44.5 mm
Width
52 mm
Length
188 mm
Number of connections round conductor total
1
Number of connections round conductor 8 mm
0
Number of connections round conductor 10 mm
0
Number of connections round conductor 8-10 mm
1
Number of connections flat conductor 30 mm
1
Number of connections flat conductor 40 mm
0
Number of connections conductor to 6 mm² fixed
0
Number of connections conductor to 16 mm² fixed
0
Number of connections conductor to 25 mm² fixed
7
Number of connections conductor to 95 mm² fixed
0
Material of contact rail
Brass
Surface of the contact rail
Nickel-plated
Material of clamp
Steel
Surface of the clamp
Galvanic/electrolytic zinc plated
