General information
LV HRC fuse link, NH000, In: 80 A, gG, Un
LV HRC fuse link, NH000, In: 80 A, gG, Un AC: 500 V, Un DC: 250 V
Ordercode YESSS
3067-8571
Product code
3NA3824
EAN code
04001869057187
Product group
Knife blade fuse
Brand
Siemens AG
Type
LV HRC fuse NH000 80A gG 500Vac/...
Product description
LV HRC fuse element, NH000, In: 80 A, gG, Un AC: 500 V, Un DC: 250 V, Front indicator, live grip lugs LV HRC fuse link SENTRON 3NA3 for selective system and line protection. The LV HRC fuse system provides effective personal, equipment and line protection with reliable disconnection in the event of overload and short-circuit. The LV HRC fuse links are available from 2 A to 1250 A in the sizes 000, 00, 0, 1, 2, 3, 4 and 4a. The versions with communication and metering function in size 2 from 80 A to 315 A. SENTRON circuit protection devices - The safe choice. Now made smarter.
Product specifications
Rated current
80 A
Voltage type
AC/DC
Utilization category according to IEC 60269
gG
Type of fuse status indicator
Top fuse status indicator
Insulated metal gripping lugs (IMGL)
No
Fuse construction type according to IEC 60269
NH000
Rated voltage AC
500 V
Rated voltage DC
250 V
Power loss at rated current
6 W
Rated switching capacity AC
120 kA
Rated switching capacity DC
25 kA
