BDS650 LED40-4S/740 I MDS D9 STD 76

Add to selection
General information
Ordercode YESSS
3052-4831
Product code
8719514199422
EAN code
08719514199422
Product group
Luminaire for streets and places
Brand
SIGNIFY
Serie
Metronomis LED
Type
Paaltoparmatuur
BDS650 LED40-4S/740 I MDS D9 STD 76 BDS650 LED40-4S/740 I MDS D9 STD 76
STOCK
IN STOCK
0 piece
Product description

Philips Metronomis LED Torch Metronomis LED is de eerste reeks paaltoparmaturen ter wereld die een palet van lichteffecten biedt waarmee aan projecten een unieke contextuele of esthetische touch verleend kan worden. Een innovatief spel van reflectie, licht en schaduw schept op de grond of in het armatuur een patroon voor extra sfeer. Vier nieuwe iconische ontwerpen, met een visuele en modulaire link naar Metronomis I, zijn beperkt tot de wezenlijke elementen. Overdag past het discrete, transparante ontwerp naadloos in zijn omgeving, terwijl het ´s nachts juist functioneel en decoratief overkomt. De flexibele, modulaire Metronomis LED wordt geleverd met een hele reeks masten en een grote verscheidenheid aan optieken en effecten. Architecten en verlichtingsontwerpers zijn hiermee in staat een uniform, consistent verlichtingsontwerp te maken dat de verschillen in stadscultuur en historie benadrukt.

Product specifications
Mounting method
Post top mounting
Lamp type
LED exchangeable
With light source
Yes
Lamp holder
Other
Housing material
Aluminium
Surface protection
Powder coating
Housing colour
Grey
Material cover
Plastic, transparent
Voltage type
AC
Nominal voltage
220 - 240 V
Type of control gear
LED operating device current-controlled
With control gear
Yes
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
Yes
Dimming DMX
No
Dimming DSI
No
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off (trailing edge)
No
Dimming phase cut-on (leading edge)
No
Dimming programmable
No
Dimming RF
No
Dimming Sine Wave Reduction
No
Dimming Zigbee
No
Degree of protection (IP)
IP66
Light distributor
Diffuser lens/optic/panel
Adjustable optics
No
Suitable for spigot size
76 - 76 mm
Impact strength
IK10
Protection class according to IEC 61140
I
Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24
No
Rated ambient temperature according to IEC 62722-2-1
25 - 25 °C
Remote control
Stand-alone control
With radio control
No
Constant light output (CLO)
No
With light regulation program control
No
With connection cable
No
Max. system power
25 W
Colour of light
White
Colour temperature
4000 - 4000 K
Colour rendering index CRI
70-79
Luminaire efficacy
134 lm/W
Power factor
0.97
Height/depth
1060 mm
Diameter
330 mm
Type of wiring
Ending
Number of poles
5
Conductor cross section
0.75 mm²
Connection type
Screwed terminal
Nominal current
90 - 120 mA
Exchangeable control gear
Yes
Colour consistency (McAdam ellipse)
SDCM5
Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq)
99 %
Lumen maintenance at median useful life of 100,000 h at 25 °C ambient (tq)
97 %
Failure rate at median useful life of 50,000 h at 25 °C ambient (tq)
5 %
Failure rate at median useful life of 100,000 h at 25 °C ambient (tq)
10 %
With light sensor
No
Max. number of luminaires per miniature circuit breaker B16 (MCB)
26
Max. number of luminaires per miniature circuit breaker C16 (MCB)
44
Operation by Bluetooth
No
Dimmable
Yes
Dimming DALI-2
Yes
Containing product according to 2019/2020/EU
Yes
Rated luminous flux according to IEC 62722-2- 1
3360 - 3360 lm
Solar powered
No
With integrated PV panel
No
Built-in battery
No
Suitable for off-grid power system
No
Dimming D4i
No
Connectable conductor cross section
1 - 2.5 mm²
Zhaga-D4i certified
No
With movement sensor
No
With presence detector
No
more specifications
^
