Movement sensor/presence detector complete STEINEL
Add to selection
General information
Ordercode YESSS
3107-6874
Product code
087814
EAN code
04007841087814
Product group
Movement sensor/presence detector complete
Brand
STEINEL
Product specifications
Model
Movement sensor
Constant light control
No
HVAC-control
No
Forced switch off
Yes
Creep-under protection
Yes
Optimum mounting height
2.5 m
Staircase light controller
No
Max. reach sideways
4 m
Max. reach frontally
2.25 m
Suitable for wireless transmission
No
Remote operation
No
With remote control
No
Response value sensitivity adjustable
No
Response value luminosity adjustable
Yes
Suitable for ceiling mounting
Yes
Connection type
Screwed terminal
Material
Plastic
Halogen free
Yes
Surface finishing
Matt
Colour
White
Degree of protection (IP)
IP20
Voltage type
AC
Min. switch-on time
5 s
Max. duty cycle
60 min
Response value luminosity
2 - 1000 lx
Number of switching zones
1436
With alarm function
No
Width
109 mm
Height
70 mm
Depth
109 mm
Diameter
109 mm
Suitable for wall mounting
No
With acoustic sensor
No
With connection cable
Yes
Product information
