General information
Steinel Bewegingsmelder IS 3360 COM1 vierk. opbouw
Steinel Bewegingsmelder IS 3360 COM1 vierk. opbouw
Ordercode YESSS
2329-1356
Product code
010478
EAN code
04007841010478
Product group
Movement sensor/presence detector complete
Brand
STEINEL
Serie
IS
Type
Sensoren
Product description
Verziend. En met zicht naar alle kanten. Grote ruimtes, parkeergarages en hallen met plafondhoogtes tot 4 m bieden zelden montagemogelijkheden per strekkende meter. Daarom zijn hier bewegingsmelders met een grote reikwijdte nodig. Zoals de IS 3360. Hij registreert tangentiaal iedere beweging binnen 20 meter. En dat bij montagehoogtes tot wel 4 meter. Kortom: een IS 3360 dekt een oppervlak van meer dan 1000 m²! STEINEL infraroodtechnologie die nakomt wat hij belooft.
Product specifications
Model
Movement sensor
Constant light control
No
HVAC-control
No
Forced switch on
Yes
Forced switch off
Yes
Animal zone
No
Creep-under protection
Yes
Networkable
Yes
Optimum mounting height
2.8 m
Staircase light controller
Yes
Bridging switch
Yes
Max. reach sideways
20 m
Max. presence range
3 m²
Max. reach frontally
20 m
Diameter reach on floor
8 m
Suitable for wireless transmission
No
Remote operation
Yes
With remote control
No
Response value sensitivity adjustable
No
Response value luminosity adjustable
Yes
With signal unit
Yes
Teach-function for response value luminosity
Yes
Suitable for ceiling mounting
Yes
Dim function with dimmer basic element
No
Mounting method
Surface mounted
Connection type
Other
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Anti-bacterial treatment
No
Colour
White
RAL-number (similar)
9003
Transparent
No
Degree of protection (IP)
IP54
Voltage type
AC
Frequency
50 - 60 Hz
Min. switch-on time
5 s
Max. duty cycle
15 min
Switch-off delay
300 s
Detection angle horizontal
360 - 360 °
Response value luminosity
2 - 1000 lx
Max. switching power
2000 W
Suitable for C-load
Yes
Number of switching zones
1416
Max. starting current
110 A
Min. starting current
0.01 A
Substation input
No
With alarm function
No
Width
95 mm
Height
65 mm
Depth
65 mm
Diameter
95 mm
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Suitable for wall mounting
No
With connection cable
Yes
