Ceiling-/wall luminaire STEINEL
Add to selection
General information
Ordercode YESSS
1237-2616
Product code
003753
EAN code
04007841003753
Product group
Ceiling-/wall luminaire
Brand
STEINEL
Product specifications
Suitable for suspended mounting
No
Suitable for ceiling mounting
No
Suitable for built-in mounting
No
Suitable for surface mounting
No
Suitable for light line configuration
No
Suitable for workplace according to EN 12464-1
No
Lamp type
LED not exchangeable
With light source
Yes
Housing material
Aluminium
Housing colour
White
Material cover
Glass opal
Type of grid
None
Voltage type
AC
Nominal voltage
230 - 240 V
Type of control gear
LED operating device current-controlled
With control gear
Yes
Dimming DALI
No
Dimming manufacturer's proprietary system
Yes
Light distributor
None
Light distribution
Symmetric
Beam angle
> 80° - Extreme wide beam
Light outlet
Direct
Impact strength
IK00
Protection class according to IEC 61140
I
Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24
No
Rated ambient temperature according to IEC 62722-2-1
-20 - 40 °C
Suitable for emergency lighting
No
With movement sensor
Yes
With light sensor
Yes
Covering of the luminaire with thermally insulating material possible
No
With air slots
No
Max. system power
8 W
Colour temperature
3200 - 3200 K
Colour rendering index CRI
60-69
Width
102 mm
Height/depth
122 mm
Length
270 mm
Type of wiring
Ending
Connection type
Other
Surface protection housing
Other
Dimmable
No
