Ceiling-/wall luminaire STEINEL
Add to selection
General information
Ordercode YESSS
1856-5444
Product code
005535
EAN code
04007841005535
Product group
Ceiling-/wall luminaire
Brand
STEINEL
Product specifications
Suitable for suspended mounting
No
Suitable for ceiling mounting
No
Suitable for built-in mounting
No
Suitable for surface mounting
Yes
Suitable for light line configuration
No
Suitable for workplace according to EN 12464-1
No
Lamp type
Other
With light source
No
Lamp holder
E27
Housing material
Plastic
Housing colour
Black
Material cover
Glass transparent
Type of grid
None
Voltage type
AC
Nominal voltage
230 - 240 V
Type of control gear
Not required
With control gear
Yes
Dimming 0-10 V
No
Dimming 1-10 V
No
Dimming DALI
No
Dimming DMX
No
Dimming DSI
No
Dimming potentiometer (integrated)
No
Dimming manufacturer's proprietary system
No
Dimming mains voltage modulation
No
Dimming phase cut-off (trailing edge)
No
Dimming phase cut-on (leading edge)
No
Dimming programmable
No
Dimming RF
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming with push-button
No
Light distributor
None
Light distribution
Symmetric
Beam angle
> 80° - Extreme wide beam
Light outlet
Direct
Impact strength
IK03
Protection class according to IEC 61140
II
Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24
No
Rated ambient temperature according to IEC 62722-2-1
-20 - 40 °C
Suitable for emergency lighting
No
With movement sensor
Yes
With light sensor
Yes
Covering of the luminaire with thermally insulating material possible
No
With air slots
No
Filament test according to IEC 60695-2-11
650 °C - 30 s
Suitable for lamp power
60 - 60 W
Max. system power
60 W
Width
215 mm
Height/depth
312 mm
Length
229 mm
Type of wiring
Suitable for loop-through wiring
Number of poles
2
Conductor cross section
2.5 mm²
Connection type
Other
Surface protection housing
Other
Dimmable
No
Product information
