General information
FIN RELAIS 1W 6A 12VDC S.
FIN RELAIS 1W 6A 12VDC S.
Ordercode YESSS
0091-5565
Product code
34.51.7.012.5010
EAN code
08012823217185
Product group
Switching relay
Brand
Finder
Serie
34
Type
34.51.7.012.5010
Product description
Smal insteek-/printrelais, 1 wisselcontact 6 A /250VAC1, spoelspanning 12VDC sensitief, contactmateriaal AgNi + Au (5um verguld)
Product specifications
Type of electric connection
PCB connection
With detachable clamps
No
Nominal current
6 A
Rated control supply voltage DC
12 - 12 V
Voltage type for actuating
DC
Drive, polarization
Polarity free
Drive, switching attitude
Mono stable
Number of contacts as normally closed contact
0
Number of contacts as normally open contact
0
Number of contacts as change-over contact
1
With forced-guided contacts
No
Type of switch contact
Single contact
Complete with socket
No
With LED indication
No
Width
5 mm
Height
15 mm
Depth
28 mm
Material of contact surface
Gold
Material contact
Silver nickel (AgNi)
Relay technology category according to IEC 61810-7
RT II
Voltage type (operating voltage)
DC
Operating voltage DC
8.4 - 18 V
Max. starting current
10 A
