General information
Aanwezigheidssensor opbouw PIR, 230V, 10A, HVAC, Ø10m, 80m², Wit
Aanwezigheidssensor opbouw PIR, 230V, 10A, HVAC, Ø10m, 80m², Wit
Ordercode YESSS
3109-6687
Product code
870478
EAN code
08716643079144
Product group
Movement sensor/presence detector complete
Brand
Lumiko
Serie
Sensoren
Type
OB-PIR-ECO-W
Product description
Aanwezigheidssensor opbouw PIR, 230V, 10A, HVAC, Ø10m, 80m², Wit
Product specifications
Model
Movement sensor
Constant light control
No
HVAC-control
Yes
Animal zone
No
Networkable
No
Scan angle
360 °
Optimum mounting height
2.5 m
Max. reach sideways
5 m
Max. presence range
154 m²
Max. reach frontally
2 m
Diameter reach on floor
10 m
Suitable for wireless transmission
No
Remote operation
Yes
With remote control
No
Response value sensitivity adjustable
Yes
Response value luminosity adjustable
Yes
Teach-function for response value luminosity
Yes
Suitable for ceiling mounting
Yes
Dim function with dimmer basic element
No
Mounting method
Surface mounted
Connection type
Screwed terminal
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Anti-bacterial treatment
No
Colour
White
RAL-number (similar)
9016
Transparent
No
Degree of protection (IP)
IP55
Voltage type
AC
Frequency
50 - 60 Hz
Min. switch-on time
30 s
Max. duty cycle
30 min
Detection angle horizontal
60 - 360 °
Response value luminosity
10 - 2000 lx
Max. switching power
2300 W
Number of switching zones
1
Max. starting current
117 A
Substation input
Yes
With alarm function
No
Width
111.7 mm
Height
39.9 mm
Diameter
111.7 mm
Max. switching power LED
400 W
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Nominal voltage
220 - 240 V
With acoustic sensor
No
With connection cable
No
Ceiling built-in mounting without installation box
No
Compatible with Casambi
No
Movement sensor/presence detector technology
Passive infrared
